Product
FlexPAK
Brand NEDERMAN
Category FlexPAK
Subcategory
Frequency controlled compact high vacuum dust collector unit to be used for many different applications. Typically 2-10 users.
Description

The FlexPAK is a frequency controlled high vacuum dust collector unit. The unit is designed for the extraction of welding fume, grinding dust, metal chips etc. FlexPAK is suitable for cleaning the workplace, the shop floor and machines. It is also very suitable for on-tool and on-torch applications. FlexPAK regulates the speed of the motor automatically depending on the vacuum demand. Compared to traditional controllers, FlexPAK provides an optimal, and well-balanced vacuum according to the need, ensuring energy-saving operation. The FlexPAK have different running modes to meet specific customer needs. The FlexPAK can easily switch between generating as much vacuum as possible, typically for applications with long piping or material transportation, or maintaining a constant vacuum level, typically useful for welding fume or grinding dust applications.

  • Easy to install
  • Built in PLC functions
  • Low operating cost
  • Reliable
  • Suitable for a wide range of applications
Technical data
Certifications CE
Noise level (dB(A)) 70
Protection class IP 42
Installation Indoor, Outdoor
Material C2 according to ISO 12944-2
Suitable for combustible dust No
Filter cleaning method Reverse air pulse
Material recycling (%) 93,6
Application Granulate, Grit, Fumes, Chip, Dust
Working pressure (in. wg) 80-140
Dustbin volume (gal) 18.5
Max Airflow (cfm) 765
Filter Area (ft²) 64,5
Power Voltage (V) 460
Frequency (Hz) 50/60
No of phases 3
Filter type Bag
Number of filter elements 1
Filter material Polypropylene
Compressed air requirement 87-101.5 psi
Max vacuum (in. wg) 140.5
Inlet (inch) 5.91
Weight (lbs) 968
Power (Hp) 29
